Item ID
L4006A1959
Description
High or Low Limit Aquastat, 40°F to 180°F Range, SPST, Contacts Break on Temperature Rise, 180F Factory Stop, Non–Adjustable Differential, Less Well, 3/8" x 2-7/8" Copper Bulb, 3" Capillary
Manufacture
Honeywell
Item Desc
HONEYWELL AQUASTAT 40-80 ADJUSTABLE
Application
High or Low limit
Approvals, American Gas Association
AGA Certified
Approvals, Canadian Standards Association
Certified: File No. LR95329-1
Approvals, Underwriters Laboratories Inc#
UL Component Recognized: File No. MP466, Vol. 6, Sec.1, Guide No. MBPR2
Bulb Size
3/8" x 2-7/8" copper
Capillary Length
3"
Differential Temperature
5 F Fixed
Dimensions
Case--5-5/8" high x 2" wide x 2-1/8" deep
Electrical Ratings
At Full Load-- 8A @ 120 Vac: 5.1A @ 240 Vac; At Locked Rotor-- 48A @ 120 Vac: 30.6A @ 240 Vac
Hazmat Information
UN 1294, TOLUENE, 3, II
Includes
Heat-conductive compound
Mounting
Horizontal or Vertical
Operating Temperature Range
40 F to 180 F
Switching Action
SPST, contacts break on temperature rise
Temperature Range
Maximum--150 F
Tradeline Value
Tradeline
Mfg# Part Number
L4006A1959
• Totally enclosed Micro Switch snap-acting switches operate on temperature rise to setpoint. • Visible control point scale and external adjustment screw permit easy setting. • Horizontal or vertical insertion of the sensing element. • Direct or well immersion of the sensing element. • Remote bulb model may be used to sense air temperature in ducts and in outside air sensing applications. • UL limit rated device.
